12. Configuration Examples
12.1 Pre-defined Values
QoS Action
Prior to adding a new meter or when configuring a policy, an in-profile and out-profile action is
added. The action itself is referenced to by a numeric number. You can use any of the default
actions or if you wish, you can create a new action prior to configuring a meter or adding a new
policy. Please use the following command to view the QoS actions available.
• 5530-24TFD(config)#show qos action
Id Name Drop Update 802.1p Set Drop Extension Storage
DSCP Priority Precedence Type
_____ ________________ _____ ______ ____________ ___________ _________ _______
1 Drop_Traffic Yes Ignore Ignore High Drop ReadOnl
2 Standard_Service No 0x0 Priority 0 High Drop ReadOnl
3 Bronze_Service No 0xA Priority 2 Low Drop ReadOnl
4 Silver_Service No 0x12 Priority 3 Low Drop ReadOnl
5 Gold_Service No 0x1A Priority 4 Low Drop ReadOnl
6 Platinum_Service No 0x22 Priority 5 Low Drop ReadOnl
7 Premium_Service No 0x2E Priority 6 Low Drop ReadOnl
8 Network_Service No 0x30 Priority 7 Low Drop ReadOnl
9 Null_Action No Ignore Ignore Low Drop ReadOnl
55001 UntrustedClfrs1 DPass Ing 1p Ignore Low Drop Other
55002 UntrustedClfrs2 DPass 0x0 Priority 0 High Drop Other
IP Element
When setting up an ip-element, you have the option of selecting any of the following default
parameters. Also, if you wish, you can add user-defined protocol and port numbers.
Table 8: Pre-defined IP Element Values
Feature Pre-defined Numerical
Value
Parameter
DSCP -1 Ignore
0 to 63 Decimal DSCP value
Protocol 6 TCP
1 ICMP
2 IGMP
17 UDP
46 RSVP
Src/Dst Port 69 TFTP
21 FTP Control
20 FTP Data
23 Telnet
25 SMTP
80 HTTP
443 HTTPS
