Filters and QoS Configuration for ERS 5500
Technical Configuration Guide v2.0 NN48500-559
___________________________________________________________________________________________________________________________
Nortel Confidential Information Copyright © 2008 Nortel Networks. All Rights Reserved.
External Distribution
47
Id: 1
Address Type: IPv4
Destination Addr/Mask: Ignore
Source Addr/Mask: Ignore
DSCP: Ignore
IPv6 Flow Id: Ignore
IPv4 Protocol / IPv6 Next Header: UDP
Destination L4 Port Min: 80
Destination L4 Port Max: 80
Source L4 Port Min: Ignore
Source L4 Port Max: Ignore
Session Id: 0
Storage Type: NonVolatile
Id: 2
Address Type: IPv4
Destination Addr/Mask: Ignore
Source Addr/Mask: Ignore
DSCP: Ignore
IPv6 Flow Id: Ignore
IPv4 Protocol / IPv6 Next Header: UDP
Destination L4 Port Min: 69
Destination L4 Port Max: 69
Source L4 Port Min: Ignore
Source L4 Port Max: Ignore
Session Id: 0
Storage Type: NonVolatile
Id: 3
Address Type: IPv4
Destination Addr/Mask: Ignore
Source Addr/Mask: Ignore
DSCP: Ignore
IPv6 Flow Id: Ignore
IPv4 Protocol / IPv6 Next Header: UDP
Destination L4 Port Min: 137
Destination L4 Port Max: 137
Source L4 Port Min: Ignore
Source L4 Port Max: Ignore
Session Id: 0
Storage Type: NonVolatile
12.2.3 Verify Classifier and Classifier Block Configuration
Step 1 – Verify that the 3 Classifiers
ERS5500-24T# show qos classifier
Result:
Id Classifier Classifier Criteria Criteria Session Storage
Name Set Id Type Id Id Type
_____ ________________ __________ ________ ________ __________ ___________
1 c1 1 IP 1 0 NonVolatile
2 c2 2 IP 2 0 NonVolatile
3 c3 3 IP 3 0 NonVolatile
55001 UntrustedClfrs1 55001 L2 55001 0 Other
55002 UntrustedClfrs2 55002 L2 55002 0 Other
Step 3 – Verify that the Meter Configuration
ERS5500-24T#show qos meter
Result:
Id: 1
Name: m1
