4. Read Status Read Status Options
20 AFP-300/AFP-400 Operations PN 50260:C1 05/22/97
Holiday Zones Figure 19 shows the typical format for displaying software zone F7 (Holiday zone):
Figure 19 Holiday Zone Screen
NAC Coding Zone Figure 20 shows the typical format for displaying NAC coding using software zone F8:
Figure 20 NAC Coding Zone Screen
The NAC coding selection indicates the type of coding applied to each of the four panel
Notification Appliance Circuits that list zone F8 in their CBE. Zone F8 does not affect
addressable control modules. NAC coding selections include the following:
• March Time (default) – 120 PPM (Pulses Per Minute)
• Alert signal – 20 PPM; General alarm signal: Steady on
• California – 10 sec. on, 5 sec. off, repeats
• Temporal – 0.5 on, 0.5 off, 0.5 on, 0.5 off, 0.5 on, 1.5 off, repeats
Pre-Alarm Zone Figure 21 shows the typical format for displaying software zone F9 (Pre-Alarm):
Figure 21 Pre-Alarm Zone Screen
Note: Refer to the AFP-300/
AFP-400 Programming Manual
for more information on
Pre-Alarm settings.
You can list zone F9 in the CBE of any control point. The Pre-Alarm zone turns on if
any detector reaches a Pre-Alarm threshold. Zone F9 indicates the beginning of an
alarm, or when the detector needs maintenance.
OFF HOLIDAY FUNCT 01/01 03/38 05/26
06/03 07/04 09/04 11/23 11/24 12/25
A Day/Month program selection for “Holiday”
days of the month.
OFF CODING FUNCTION CODE TYPE
MARCH TIME F08
Indicates NAC coding zone F8
Indicates the NAC coding selection
Refer to “Operating Coding
Functions” on page 12.
OFF PRE-ALARM FUNCT ALERT
F09
