5. Voice Alarm Systems Selecting AMG Tones and Messages
28 AFP-300/AFP-400 Operations PN 50260:C1 05/22/97
Selecting AMG Tones and Messages
Note: Refer to Appendix A,
Annunciators in the AFP-300/
AFP-400 Installation Manual for
detailed instructions on using an
AMG-1 in ACS mode. For
programming instructions, refer
to the AFP-300/AFP-400
Programming Manual.
Overview You can select AMG tones and messages by setting AMG DIP switches. An
AMG appears as an annunciator to the system and operates on annunciator address 01.
Operating an AMG, therefore, affects control panel programming and annunciator
switch settings.
1. Select ACS=Y in the System Function screen (Figure 30):
Figure 30 System Function Screen
2. Enter Annunciator Selection Group 1 for Annunciator Address 1(Figure 31):
Figure 31 Annunciator Selection Screen
Setting the AMG DIP Switch (SW2) Set the rocker switches on the AMG DIP Switch
(SW2) as follows:
• To set a switch on, push the rocker switch to On.
• To set Message Select switches, refer to Table 23 or Table 24. For example, if you
set switch 2 to Off, refer to the settings in Table 23 for setting switches 6-8.
Table 22 AMG DIP SW2 Rocker Switch Settings
Switch Number On Off
1 – Low level Audio Four-wire supervision of Low
Level Audio.
Disabled
2 – Tone/Message select
Refer to
Table 23 for setting
switches 6-8
Refer to Table 24 for
setting switches 6-8
3 – Receive Only Disables the AMG All Call
function.
Disabled
4 – Voice RAM Enable A Record a message in VRAM-A Disabled
5 – Voice RAM Enable B Record a message in VRAM-B Disabled
6 – Message Select
See
Table 23 or Table 24 for settings.
7 – Message Select
See
Table 23 or Table 24 for settings.
8 – Message Select
See
Table 23 or Table 24 for settings.
SIL INH=000 AUTO=000 VERIFY=00 USA TIME
TERM_SUPERV=NO LocT BLINK=Y ST=4 ACS=Y
Toggle between N (default) or Y
ANNUN SELECTION1: A1=1 A2=* A3=* A4=*
A5=* A6=* A7=* A8=* A9=* A10=* UDACT=Y
Annunciator Selection Group 1
Annunciator Address 1
