Section 3 Installation Installation Checklist
18 NFS-3030 Installation PN 51330:C 10/28/2003
Printer or other output device(s) Section 3.18 “Installing Printers”
Network devices Noti•Fire•Net Version 4.0 & Higher Manual, and/or
Installation document for specific device(s)
7. Wire the Signaling Line Circuits. Section 3.19 “Wiring a Signaling Line Circuit (SLC)” and SLC Wiring
Manual
8. Calculate the proper battery rating. Main Power Supply Manual
9. Install main power supply & batteries in
separate enclosure. Run cable to main
& optional power supplies, DC power
outputs, relays, etc.
Section 3.15 “Connecting Power Sources and Outputs”
Section 3.16 “UL Power-limited Wiring Requirements”
WARNING: Do not activate power at this time. Do NOT connect batteries.
Main power supply. Main Power Supply Manual
BB-100/200 Cabinet Installation Instructions
Auxiliary power supply and/or
external battery charger
Auxiliary power supply manuals and/or battery charger manuals
Note: If using multiple power supplies with one set of batteries, refer to
main power supply manual for connection requirements.
10. Check that all mounting holes are secured to insure a proper Earth Ground connection.
11. Connect wire shielding to Earth Ground.
12. Remove insulator from lithium battery
on CPU
Section 3.5.1 “Memory-Backup Battery”
13. Apply AC power to the control panel by placing the external circuit breaker to the ON position.
Do NOT connect batteries until AC power is checked (see next step).
14. Check AC power. Section 3.15.1 “Checking AC Power”
15. Connect the batteries using interconnect cable as described in power supply manual.
16. Install the dress panels, doors and
covers.
CAB-3/CAB-4 Series Cabinet Installation Document
17. Program the control panel. Programming Manual.
18. Field test the system. Section 5 “Testing the System”
Table 2 Installation Checklist (Sheet 2 of 2)
Task Refer to:
!
