Appendix A Electrical Specifications Operating Power
62 NFS-3030 Installation PN 51330:C 10/28/2003
Appendix A Electrical Specifications
A.1 Operating Power
DC Power
The control panel requires connection to a +24 VDC regulated power supply, UL/ULC-listed for fire
protective service, that can supply 0.1 amps continuous for CPU-3030ND (0.3 amps for CPU-3030D).
For complete battery/current draw calculations, refer to the main power supply manual; if using an
auxiliary power supply, there may be additional calculations in that manual.
A.2 SLC Loops
Listed below are specifications for a Signaling Line Circuit loop:
A.3 Notification Appliance Circuits
Notification Appliance Circuits are provided by panel circuit modules and SLC loop devices. Non-
hazardous agent releasing devices may be connected on the SLC loop.
If using an auxiliary power supply, refer to that installation manual for product-specific specifications.
Refer to the Device Compatibility Document for compatible devices and notification appliances.
Item Value
Voltage 24 VDC nominal, 27.6 VDC maximum
Maximum length
The maximum wiring distance of an SLC using 12 AWG (3.25 mm
2
)
twisted-pair wire is 12,500 ft. (3810 m) per channel.
Note: Refer to Appendix A.4 “Wire Requirements” for limitations.
Maximum current 130 mA LCM-320
100m A LEM-320
400 mA max* Single SLC loop
*Max short circuit...circuit will shut down until short circuit condition
is corrected.
Maximum resistance 50 ohms (supervised and power-limited). For additional notes on
SLC resistance values, see Section 5.3 “Operational Checks”.
Item Value
Max. wiring voltage drop 2 VDC (except CMX-2 which is 1.2 VDC)
Nominal operating voltage 24 VDC
Current for all accessories connected to
the AMPS-24/E
1.0 A continuous
End-of-Line Resistors (ELRs) ICM-4RK, ICE-4, VCM-4RK, VCE-4, and DCM-4RK:
4.7K, 1/2 watt (2 watts on 70 Vrms audio)
XP5-M, XP5-C, FCM-1 Modules: 47K, 1/2 watt
