28
Relation between temperature (°C) and nominal resistance (Ohm) of CH probe SR and DHW probe SS.
T (°C) 02468
0 27203 24979 22959 21122 19451
10 17928 16539 15271 14113 13054
20 12084 11196 10382 9634 8948
30 8317 7736 7202 6709 6254
40 5835 5448 5090 4758 4452
50 4168 3904 3660 3433 3222
60 3026 2844 2674 2516 2369
70 2232 2104 1984 1872 1767
80 1670 1578 1492 1412 1336
90 1266 1199 1137 1079 1023
No. 7 chart – “Temperature - Nominal resistance” relation of temperature probes
