ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC
Communication Ports
Serial (option*) RS-232, RS-485, Software configurable ports
Baud rate: 9600 bps to 115.2 kbps
Ethernet Single port; copper 10/100 Base-TX (standard)
Single port; LC fiber 100 Base-FX (option)
Analog Transducer Outputs (option*) Refer to section 7.0 for specifications
*Either the serial port or analog output may be ordered as an option, but not both
Accuracy
Accuracies are specified at nominal Frequency and 25C, (unless otherwise noted). Unless noted, all values are true RMS
and include Harmonics to the 31st
minimum
.
Voltage AC: Better than 0.1% of reading (20 to 150 V rms, input-to-case). (+/-
25ppm/De
C
Voltage Aux Only included with
meters manufactured
with the monitoring
option
AC/DC: Better than 1.0% of reading
Current Input option 1 (Internal
Isolation - 1A ac)
Better than 0.1% of reading +/- 20uA (>0.1A to 2.0A, -20C to 70C)
Better than 0.1% of reading +/- 50uA (0.01A to 0.1A, -20C to 70C)
Minimum reading 1mA
Input option 5 (Internal
Isolation - 5A ac)
Better than 0.1% of reading +/- 100uA (>0.5A to 10.0A, -20C to 70C)
Better than 0.1% of reading +/- 250uA (0.05A to 0.5A, -20C to 70C)
Minimum reading 5mA
Input option C (External
Split-Core CTs)
Better than 0.1% of reading +/- 100uA (>0.5A to 10.0A, -20C to 70C)
Better than 0.1% of reading +/- 250uA (0.05A to 0.5A, -20C to 70C)
Minimum reading 5mA
Frequency +/- 0.001 Hertz +/- 0.001 Hertz
Power Meets or exceeds IEC
60687 0.2S
Meets or exceeds IEC 60687 0.2S
