ML0035 September 27, 2017 - 89 - Copyright 2017 Bitronics, LLC
6.11.7 Phase Angles
The M65x measures the Fundamental Phase Angles for all Currents, Line-to-Neutral
Voltages, and Line-to-Line Voltages. The Phase Angles are in degrees, and all are
referenced to the V
A-N
Voltage, which places all Phase Angles in a common reference
system. Values are from -180 to +180 Degrees. Note that the phase angles are only
available in the TUC register set and use calculation type T8 (see Modbus and DNP3
Protocol manuals for more detail). As with other measurements, the Phase angles
can be mapped to analog outputs or used in custom display screens.
6.12 Heartbeat and Health Check
M65x meters provide a Heartbeat State Counter Register that allows the user to
determine the time between successive polls. This counter will increment by the
number of milliseconds that have elapsed since the last time the data was updated.
Another use of this register is as a visual indicator that the data is changing; it allows
users of certain MMIs to identify disruption in the polling of the instrument. The
Heartbeat State Counter is a full 32-bit counter that rolls over at 4,294,967,295
(4,294,967 seconds). The counter starts at zero on power-up, and is NOT stored in
non-volatile memory.
M65x meters have several self-tests built in to ensure that the instrument is performing
accurately. The results of these self-tests are available in the Health Check register
which is a simple 16-bit binary value. Each bit represents the results of a particular
self-test, with "0" indicating the test was passed, and "1" indicating the test was failed.
If Health status failures occur, the meter may have experienced an operational failure.
The table below provides a reference of error codes. The Health Check value shown
in the M650 web live data page is a hexadecimal representation of the binary value.
For example, a Health Check value of 0000 0014 is the equivalent of the binary value
000000000010100. The “1” shown in bit 2 and bit 4 represents a failed test in those
bits which indicates a checksum error for both the gain and phase on the calibration.
Contact the factory for further instructions.
Health Check Error Codes
Bit Description
0 Checksum error on analog output (either 0-1mA or 4-20mA) calibration
constants
2 Checksum error on
ain calibration of inputs
4 Checksum error on phase calibration of inputs
5 Clip - Input Ove
-Ran
e
12 Indicates firmware download in pro
ress and measurements are offline
