Novatech Bitronics 50 Series User Manual

49
ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC
4.1.2 Keypad Functions for Display Mode
Measurements screens may be stepped through manually by pushing the up and down arrow
keys. Pushing the Toggle (Exit) key turns the scroll function off and on. When the scroll
function is activated, the measurement screens will automatically step through the user-
defined screens. Auto scroll state (ON/OFF) is stored in non-volatile memory. Pressing the
Home (Enter) key will bring up the home screen. The factory default home screen will be
Amps A, B, C. If a user enables or disables screens via the front display buttons from Setup
Mode -
1.6
Scrn Ena, then the home screen will automatically become the 1
st
enabled screen.
The home screen can be setup as any one of the enabled screens by simultaneously
pressing the Home (Enter) and Toggle (Exit) buttons when on the desired screen and can
also be done through the web server Settings tab.
Table 1 –Button Functions
Button Displa
y
Mode Function Setup Mode Function
Up Arrow Next measurement/value Next menu item
Down Arrow Previous
measurement/value
Previous menu item
or
Y
(
Yes
)
when prompted
Home (Enter) Scroll to designated home
screen
Enter selected submenu (or
configuration item), or
Increments the hightlighted
digit when entering number,
or
IP address, or
N
(
No
)
when prompted
Toggle (Exit) Toggle Auto Scroll On/Off Exits current menu
selection and moves up to
next higher menu level.
Returns to display mode on
exit from main setup menu
Combination Up and
Exit keys
Enter Setup Mode
(Resets and configuration
setting are done in the
setup menu
)
Combination Up and
Down Keys
Resets Demand Values
Ente
r
E
XIT

