Novatech Bitronics 50 Series User Manual

18
ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC
Physical
Connections Protective
Conductor
Terminal
10-32 Studs for connection with protective earth ground. Recommended Torque: 12 In-Lbs,
1.36 N-m
Cable temperature ratin
g
: 85C minimum
Current
(CT)
Internal Isolation - Current Input Option 1 or 5. 10-32 Studs for current inputs. Recommended
Torque: 12 In-Lbs, 1.36 N-m
Cable temperature ratin
g
: 85C minimum
External Split-Core CTs – Current Input Option C: Terminal Block accepts #22-12 AWG (0.35
to 3.3mm
2
) wire, or terminal lugs up to 0.325" (8.26mm) wide.
Recommended Torque: 9 In-Lbs, 1.02 N-m
Cable temperature ratin
g
: 85C minimum
Voltage
(VT) &
(AUX
PWR)
Terminal Block accepts #22-10 AWG (0.35 to 5mm
2
) wire, or terminal lugs up to 0.375"
(9.53mm) wide. Precautions must be taken to prevent shorting of lugs at the terminal block.
A minimum distance of 1/8" (3mm) is recommended between uninsulated lugs to maintain
insulation requirements. Recommended Torque: 9 In-Lbs, 1.02 N-m
Cable temperature ratin
g
: 85C minimum
Serial Port 6 position removable terminal block, accepts 26-14AWG solid or 26-12 AWG stranded wire.
Recommended Torque 7 in-lbs, 0.79 N-m.
Cable temperature ratin
g
: 85C minimum
Ethernet RJ45, 8 position modular jack, Category 5 for copper connection; 100m (328 ft.) UTP
(
unshielded twisted pair
)
cable.
Weight
(
t
y
pical
)
1.8 lbs (.8 kg)
Size Industry standard 4” round case, 7.0 inches long

Novatech Bitronics 50 Series Specifications

General

Brand	Novatech
Model	Bitronics 50 Series
Category	Measuring Instruments
Language	English
