ML0035 September 27, 2017 - 65 - Copyright 2017 Bitronics, LLC
Settings Page Selections:
From the Settings page screen you can select one of the following selections:
Identity– This page allows the user to enter information that is necessary to identify
the meter. It gives an identity to a particular M650. Each M650 should have
different information entered for its identity.
Input – This page allows for the selection of wiring configuration, setup of CT and
PT ratios, demand intervals, and TDD denominator.
Network – This page allows the user to change the network configuration settings
for IP address, gateway and router address.
Serial Port – This page allows user configuration for the serial port settings. Note
that if no serial port is ordered this setting won’t appear and if the transducer output
option is selected then that setting will replace serial.
Protocol – This page allows user configuration of the protocols – DNP or Modbus
Screen Enable - Allows the screens shown on the M650 display (front panel) to be
enabled or disabled by the user.
Custom Screens – Allows the user to set up custom display screens if the standard
screens don’t meet their needs.
Load/Store Settings – This page allows you to save and retrieve settings for the
M650 meter
Password Security – This page allows the user to set a password and to enable or
disable access to front display configuration (M650 and M653)
Firmware Upload – This page allows the user an interface to browse for or type in
the location on their PC of new firmware for purposes of uploading to the unit.
Screen shots showing the selections to be made for each of the above selections
follow on the next few pages. Default values are shown where applicable.
M650 configuration changes require the unit to be rebooted. Configuration settings
for the M650 are stored in flash memory.
