Novation Impulse User Manual

33
English
2. Faders – Impulse 25 only
Clicking the fader area of the Impulse image in the Mapping Editor window will cause the
display to change to a set of nine faders (initially Tracks 1 – 8 plus the Master fader). As
Impulse 25 has just one physical fader, it will initially be assigned to Track 1.
Using Track Up/Down (these are shifted functions of the two Octave buttons
9
) it is possible
to sequentially increment/decrement track assignment to the physical fader, thus allowing you
to build up your mix one channel at a time. See “Track Up/Down” on page 34.
As with the encoders, there are additional pages of the Mapping Editor window. These may be
accessed in the same way as described above.
3. Faders – Impulse 49 and 61
Clicking the fader area of the Impulse image in the Mapping Editor window will cause the
display to change to a set of nine faders. These represent the nine faders on Impulse.

Novation Impulse Specifications

General

Velocity Sensitive	Yes
Aftertouch	Yes
Faders	9
Knobs	8
Transport Controls	Yes
Arpeggiator	Yes
Keyboard Type	Semi-weighted
Aftertouch Type	Channel
Key Count	25, 49, 61
Pads	8
Display	LCD
MIDI I/O	MIDI In/Out
Power	USB powered
Type	MIDI Controller
Connections	USB, MIDI In/Out, Sustain Pedal
Software	Ableton Live Lite, Novation Bass Station
Pads Type	Velocity-sensitive backlit pads
Controls	Knobs, faders, buttons, pads
Display Type	LCD
Pedal Inputs	Sustain, Expression
Software Included	Ableton Live Lite, Novation Bass Station
Power Supply	USB
Dimensions (49-key)	864mm (W) x 332mm (D) x 100mm (H)
Weight (49-key)	5 kg
