Novation ZeRO SL MkII User Manual

7
non-ASSIGnABLE SyStEM ContRoLS
They have fixed functions, as follows:
9) 144 character LCD display: Displays the names and values of each row of assignable controls from both the left
and right side of the ZeRO SL MkII
10) Automap Buttons: These 6 buttons are used for Automap Software navigation and control.
11) Preview Button: Press and hold this button and touch any control on the Zero SL MkII to preview the whole row’s
parameter information on the LCD.
12) Page Up / Down Buttons: Use these to scroll through pages of options when in a menu or through pages of additional
control information when in an Advanced template. These buttons have different specific functions when in certain
Advanced templates and when using Automap.
13) Mode and System Buttons (Automap, Quick, Edit, Global, Write, Transport): Use these to access the different modes
and menus of the ZeRO SL MkII.
14) Speed Dial /Template/Preset knob: The Speed Dial function acts as a way of controlling the computers mouse using
the ZeRO SL MkII hardware. When this button is pressed down it acts as a template selector (when in Advanced
mode) and as a preset selector (Automap mode).
9
1113121311
1413

Novation ZeRO SL MkII Specifications

General

Mixer section	Yes
Product color	Silver
Scratcher type	-
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 x64

Weight and Dimensions

Depth	200 mm
Width	445 mm
Height	68 mm
