installation manual page 27
30044.0801.E.01 fast action roller doors
1.2 Speedroller Heavy
The Novoferm Speedroller Heavy is an electrically driven
fast action roller door. These doors are used in industrial
and commercial buildings for purposes of energy saving,
draught exclusion and climate control.
Specification/construction
The Novoferm fast action roller door type Speedroller is not
fitted with balance springs. The door is built up of horizontal
profiles, which are wound on a steel roller above the door
opening by means of an electric motor/gearbox. An optional
tensioning system in the vertical guides ensures that the door
curtain remains tightly tensioned during operation and in the
closed position. A reinforced 3 mm PVC door curtain material
with integrated wind bars is used. A vision section is available
as standard. The closing edge of the door consists of an
aluminium beam fitted with a flexible rubber floor seal. Vertical
side guide channels fitted with brush seals, guide and seal the
door panel. The side channels can be opened for assembly and
maintenance purposes.
Material
• galvanised steel roller.
• door curtain of reinforced 3 mm PVC, available in blue or
orange.
•side channels manufactured from folded galvanised steel
plate and fitted with brush seals.
• bottom beam made of aluminium and supplied with a flexible
soft rubber seal.
Dimensions
• as an inside or outside door ...............max. 6000 x 6000 mm
•width guide channels ............................................... 225 mm
• space required, non motor/operator side ................. 275 mm
• space required, motor/operator side ........................ 470 mm
• space required for installation, drive side ........ min. 750 mm
• headroom................................................................. 615 mm
• overall projection (from the wall) .............................. 400 mm
Drive
The drive unit consists of an electric motor/gearbox unit, which
drives the drum directly and is fitted as standard with an anti-
roll-off device. Drive unit mounted on the right (standard
location) or on the left.
Controls
The control system incorporates a variety of functions such as :
• open position duration either via a delay timer or via "push-
open/push-closed" operation.
•"Service mode"
•LED-indicators enabling rapid fault finding.
• choice of permanently open or permanently closed.
Operation
The control box has 2 push buttons (open-close) as standard,
an emergency/stop switch and a 4-pole disconnectable main
switch. Various actuators can be used: pull switch, key switch,
push button, photocell, radar, induction loop detection or remote
control. Other types on request.
Performance
the opening and closing speed is ................................ 1 m/s
Safety
•the door can be cranked open in the event of a power
failure.
•the bottom beam is fitted with a self-testing safety edge,
which stops the door and immediately causes it to re-open if
an obstacle is encountered during closure.
•the side guide channels are are fitted as standard with a
safety photocell with a reflector (400 mm from the floor). The
door will not close if the beam is broken.
Mounting structure requirements and connection
•the power supply must be present within 500 mm of the
control box.
•required installation space as indicated in the illustration
below.
•a stable, flat mounting surface or steel frame for mounting
the door
Technical specifications electric motor
mains voltage ........................................ 3N~400V/50Hz/16A
degree of protection ....................................................... IP54
temperature range ............................................... 0
°
C - 40
°
C
Accessories / Options
•plastic rain hood over roller/drive or both
•side guides painted in RAL colour
•'Break Away' bottom beam (crash resistant). Limits wind
resistance to 5 Beaufort.
•elasticated Crash proof bottom beam (limits wind resistance
to 5 Beaufort, max. 5000 x 5000 mm, door curtain material
1,2 mm).
•emergency opening facility
•other electrical supply specifications
•electrical components IP65
• frequency inverter control
opening speed .......................................................... 1,5 m/s
closing speed .......................................................... 0,75 m/s
• actuation using push buttons, pull switches, photocells,
radar detectors, induction loop detection and remote control
• half-height operation
•interlock switching in combination with another door
• traffic light switching (red/green, red or green)
