User Manual TXLD0012
Page | 22 Novoxel.com P/N T2-UM-E-ENG Rev 10
Installation
The Handpiece cradles are packed separately from the Console. Insert each cradle’s legs (marked by the
red square) fully into the designated holes on each side of the Console. You may pull the cradle slightly
out for convenience, but always make sure it is firmly held in the Console.
Connecting the Handpiece Cradles
