FASTENER TORQUE CHART
MODEL
PIN LOCK PLATE - SHCS
PART NO.
ft. lbs
(Nm)
DG16
74012025
65
(87)
DG20
74012025
65
(87)
DG30
74012025
65
(87)
DG40
74012025
65
(87)
MODEL
SLEWING RING - SHCS
PART NO.
ft. lbs.
(Nm)
DG16
74016075
225
(300)
DG20
74016075
225
(300)
74016070
225
(300)
DG30
74016080
225
(300)
74016090
225
(300)
DG40
74016080
225
(300)
74016090
225
(300)
MODEL
TOP BRACKET - HHCS
BOLT DIA.
ft. lbs
(Nm)
DG16
1"
750
(1015)
DG20
1"
750
(1015)
DG30
1-1/4"
1500
(2030)
DG40
1-1/4"
1500
(2030)
