- 22 -

LUBRICATION

AUTO LUBE GREASE LINE PRE-FILLING

G100-8050 Hose Fill Assembly

B160-4010 Grease Fitting - ¼” NPT male

DQ K301-6620 Male x Female Adapter - #6 JIC male x ¼” NPT Female
