4
SUMMARY 1. SUMMARY
1-3. Nomenclature
●Front side ●Right side
●Bottom side
Power supply
terminal block (M3)
Operation part
Nameplate
Serial communication connector
Connects to the personal computer, etc…
Sensor connector
Connects with ABSOCODER.
BCD output connector
Connects to the program No. input and current
position value output, etc…
(This is not available for VS-5F and VS-5F-1.)
Switch output connector
Connects with the switch output, etc…
Display part
S P 1
