NSD VARICAM VS-5F-1 User Manual

14
SPECIFICATION 3. SPECIFICATIONS
3. SPECIFICATIONS
3-1. VARICAM Specifications
3-1-1. General Specification
Items
Specifications
Model VS-5F, VS-5FD, VS-5FX VS-5F-1, VS-5FD-1, VS-5FX-1
Power supply
voltage
100VAC 50/60Hz 24VDC
Permissible power
voltage range
85 to 132VAC 21.6 to 30VDC
Power consumption
20VA or less
10W or less
Insulation resistance
20 M
Ω
or more between external AC power
terminals and ground
(by 500 VDC insulation resistance tester)
20 M
Ω
or more between external DC power
terminals and ground
(by 500 VDC insulation resistance tester)
Withstand voltage
1500 VAC, 60Hz for 1 minute between
external AC power terminals and ground
500 VAC, 60Hz for 1 minute between external
DC power terminals and ground
Vibration resistance 20m/s
2
10 to 500Hz, 10cycles of 5 minutes in 3 directions, conforms to JIS C 0040 standard
Ambient operating
temperature
0 to +55°C (No freezing)
Ambient operating
humidity
20 to 90 %RH (No condensation)
Ambient operating
environment
Free from corrosive gases and excessive dust
Ambient storage
temperature
-10 to +70℃
Grounding
Must be securely grounded (ground resistance of 100
Ω
or less)
Construction
Inside control panel
Mounting
- Two-point screws mounting
- DIN rail mounting
- It is possible to mount on the panel when using a panel mounting fixture “VS-K-F”
Choose the method either one.
Outside dimension
(mm)
130(W) x 81(H) x 99(D) [Refer to dimensions for details.]
Mass Approx. 0.7kg
