NSD VARICAM VS-5F-1 User Manual

68
OPERATION 8. HOW TO USE APPLIED FUNCTIONS (PARAMETER)
8-6. Output HOLD Function
This function is applicable with all VS-5F Series.
This function keeps the state of the switch output when the mode changes from the operation (RUN) mode to switch
setting (SET) mode or parameter setting (PRM) mode.
This function sets by the parameter No. 94 (Output state in SET mode).
● Parameter list
No. Name Description Setting range
Initial
value
Reference for
setting procedure
(Chapter No.)
94
Output status in
SET mode
Selects the switch output status when
changing the switch setting (SET) mode
or parameter setting (PRM) mode from
operation (RUN) mode.
Keeps the state of switch output of
operation (RUN) mode when selecting “1:
Output HOLD”.
0: Output OFF
1: Output HOLD
0
8-1-1
8-1-2
