SUMMARY 2. MODEL SELECTION WHEN ORDERING
●Model list
◆VARICAM
No.
Model
Description
①
VS-5F
100VAC model
1 program, 24 points output
VS-5FD
8 programs, 24 points output
VS-5FX
16 programs, 40 points output or 32 programs, 24 points output
VS-5F-1
24VDC model
1 program, 24 points output
VS-5FD-1
8 programs, 24 points output
VS-5FX-1
16 programs, 40 points output or 32 programs, 24 points output
◆ABSOCODER
No.
Model
Description
②
VRE-P062SAC
Diameter:
φ
62, Shaft shape: flat, servo-mount type
VRE-P062SBC
Diameter:
φ
62, Shaft shape: key way, servo-mount type
VRE-P062FAC
Diameter:
φ
62, Shaft shape: flat, flange-mount type
VRE-P062FBC
Diameter:
φ
62, Shaft shape: key way, flange-mount type
VRE-P028SAC
Diameter:
φ
28, Shaft shape: flat, servo-mount type
◆Extension sensor cable
No.
Model
Description
③
3P-S-0102-[L]
(Standard cable)
Uses this cable when ABSOCODER and VARICAM installation site are far.
The cable is able to extended maximum 100 meters.
[L]: Cable length [m]
2,3,5,8,10,15,20,25,30,35,40,45,50……100m
(If a cable length is 50m or more, it can be selected by each 10m.)
3P-RBT-0102-[L]
(Robotic cable)
◆Option
No.
Name
Model
Description
④ External display unit
NDP-A211 [*] 1
Angles and rotation speeds are able to monitor.
NDP-A211: 150 x 150 size NDP-A221: 110 x 110 size
[*]: Connection method *2
A: Parallel type B: Serial type
The serial connection type can connect max. 9 units of NDP to VARICAM.
NDP-A221 [*] 1
⑤
Setting and editing
software *1
VS-5F-EDW2
Data setting and editing are available by using a computer.
OS: Microsoft Windows/XP/Vista/7/8
⑥ I/O cable
VS-C05-[L]
(without shield)
Uses this cable at the switch output connector and BCD output connector.
[L]: Cable length 1, 2, 3, 5, 7, 10m
⑦
Cable for external
display unit
VS-C05-Z01-2
(with shield)
Uses this cable when connecting with the parallel type external display unit.
Cable length: 2m
NDP-C01-[L]
(with shield)
Uses this cable when connecting with the serial type external display unit.
[L]: Cable length [m] *3
NDP-C02-[L]
(with shield)
Uses this cable when connecting the NDP more than two units.
[L]: Cable length [m] *3
⑧
Panel-mount fixture
for VS-5F series
VS-K-F Uses this fixture for panel mounting VARICAM on the control panel.
⑨ Clamp filter ZCAT2032-0930
This is option parts for corresponding to CE marking.
Inner dimensions: φ9
(Manufacturer: TDK Corporation)
⑩
Reinforced
servo-mount fixture
SH-01 This fixture is able to use with VRE-P062SAC and VRE-P062SBC.
⑪
L type
flange-mount fixture
RB-01
This fixture is able to use with VRE-P062SAC, VRE-P062SBC,
VRE-P062FAC, and VRE-P062FBC.
In the case of using VRE-P062SAC or VRE-P062SBC, the reinforced
servo-mount fixture (SH-01) must be used.
*1: Please prepare the USB-RS-232C adapter when your computer doesn't have a RS-232C port.
*2: In the case of using VS-5F or VS-5F-1, select the serial type external display unit.
*3: The total cable length of the NDP-C01-[L] and NDP-C02-[L] is maximum 100 meters.
