NSD VARICAM VS-5F-1 User Manual

61
OPERATION 8. HOW TO USE APPLIED FUNCTIONS (PARAMETER)
● Switch output parameter (2/4)
No. Name Description and setting range
Applicable model
Reference
(Chapter No.)
VS-5F
VS-5FD
VS-5FX
97
Program No.
input format
Selects the input format of the program No. to be operated.
0: By panel key input
1: By external connector input
2: By serial communication
○ ○ 8-2
96
Protected switch
Selects whether or not the protected switch function is to be
used.
The switch Nos. 1 to 10 is set as the
protected switch when
selecting “1:VALID”.
0: INVALID 1: VALID
○ ○ ○ 8-3
95
Protected switch
cancel
Uses this function when selecting the protected switch by the
parameter No. 96 (protected switch).
The protec
ted switch setting value can be changed by
selecting “1:cancel”.
0: Do not cancel 1: Cancel
○ ○ ○ 8-3
94
Output status in
SET mode
Selects the switch output status when changing the switch
setting (SET) mode or parameter setting (PRM) mode from
operation (RUN) mode.
0: Output OFF 1: Output HOLD
○ ○ ○ 8-6
93
Timing pulse
VS-5F(-1)
VS-5FD(-1)
VS-5FX(-1)
: Switch output connector A5-pin
: Switch output connector A5
-pin and
BCD output connector B11-pin
: BCD output connector B11
-pin
○ ○ ○
8-4
8-5
Changes the timing pulse and motion detection switch
function.
Timing pulse function is selecting number of output pulses per
revolution.
0: 360 pulses
1: 180 pulses
2: 60 pulses
3: Motion detection switch
Display: 360
Display: 180
Display: 60
Display: Spd
92
Setting change
during operation
Designates the function when fine-adjusting the switch output
during the operation.
0: Change disable 1: Change enable
○ ○ ○ 10-3
90
Switch output
enabling range
Switch output connector B4-pin
Designates controlling numbers of switch output by the
switch output enabling signal.
○ ○ ○ 8-8
VS-5F(-1)
VS-5FD(-1)
VS-5FX(-1)
0
: 0 to 24
: 0 to 24
: 0 to 40
75
Motion detection
switch OFF
Designates a value that the motion detection switch output
turns OFF.
“3: Motion detection switch” needs to be selected at the
parameter No. 93 (timing pulse).
Setting range: 0 to 6000 r/min
0 r/min
○ ○ ○ 8-5
74
Motion detection
switch ON
Designates a value that the motion detection switch output
turns ON.
“3: Motion detection switch” needs to be selected at the
parameter No. 93 (timing pulse).
Setting range: 0 to 6000 r/min
0 r/min
○ ○ ○ 8-5
40
Hysteresis angle
Designates a hysteresis angle when controlling flickers of the
current position value.
Setting unit is 0.5°.
Setting range: 0.0 to 10.0°
0.0
°
○ ○ ○ 8-7
