NSD VARICAM VS-5F-1 User Manual

77
OPERATION 8. HOW TO USE APPLIED FUNCTIONS (PARAMETER)
8-12. Selecting Function of the Output Logic (Current Position Value / Speed)
This method is available for VS-5FD, VS-5FD-1, VS-5FX, and VS-5FX-1.
This function inverts the logic of the current position value output (BCD, gray code (720-division) or speed output.
It is selectable that the host controller or display unit connects to VARICAM.
Positive logic: truth-value is “1” when BCD output connector (A10 to A20 pin) output is OFF (High level).
Negative logic: truth-value is “1” when BCD output connector (A10 to A20 pin) output is ON (Low level).
This function sets by the parameter No. 78 (Logic of BCD output connector).
● Parameter list
No. Name Description Setting range
Initial
value
Reference for
setting procedure
(Chapter No.)
78
Logic of BCD
output connector
Selects the logic of current position value
output (BCD, gray code (720-division) and
speed output (binary code).
0: Positive logic
1: Negative logic
0
8-1-1
8-1-2
