NSD VARICAM VS-5F Series User Manual

60
OPERATION 8. HOW TO USE APPLIED FUNCTIONS (PARAMETER)
8-1-4. Parameter List
This is a parameter list, and refers to the each chapter for parameter details.
Default values (the factory setting values) are shown in .
● Initial parameter (1/4)
No.
Name
Description and setting range
Applicable model
Reference
(Chapter No.)
VS-5F
VS-5FD
VS-5FX
00
Initial display
Displays “00” at first when selecting the parameter setting
(PRM) mode.
○ ○ ○
02
VS-5FX output
specifications
This function must be designated at first when using
VS-5FX(-1) after delivery.
Designates the combination of program and switch output
numbers.
0: 16-program, 40-switch
1: 32-program, 24-switch
○ 7-5-2
01
ABSOCODER
rotation direction
Designates the rotation direction of ABSOCODER’s shaft in
which the current position value increase.
0: CW direction Display:
1: CCW direction Display:
○ ○ ○ 7-5-3
99
Origin point
setting
Designates the machine’s origin point (000) to VARICAM. ○ ○ ○ 7-5-4
98
Current position
setting
Designates the machine's current position value to
VARICAM by the key input.
Setting unit is 0.5°.
Setting range:0 to 359.5°
0
°
○ ○ ○ 7-5-5
