SPECIFICATION 3. SPECIFICATIONS
3-1-2. Performance Specification
Items Specifications
Model
VS-5F, VS-5F-1
VS-5FD, VS-5FD-1
VS-5FX, VS-5FX-1
Number of programs
1
8 (0 to 7)
16 (0 to 15)
32 (0 to 31)
Number of switches
24
24
40
24
Number of Multi-dogs
10 times for each switch output (0 to 9)
Position detection format
Absolute position detection
Number of detection axes
1
Output signal updating
cycle
Switch output signal: 0.176ms
Current position value output (BCD): 0.352ms to 140.6ms
Current position value output (gray code (720-division)): 0.176ms, 0.352ms to 140.6ms
Speed output (binary code): 0.352ms to 140.6ms
Internal position data reading cycle: 0.176ms
Switch output setting
method
Numeric setting with keys, or teaching setting by manual machine operation
Minimum setting unit
0.5
°
Position data valid digit
numbers
3 digits + 0.5°(Decimal point display) ( 0 to 359.5 )
Response rotation speed
900r/min (When ON / OFF zone is 1 degree.)
Setting value memory
Non-volatile memories (FRAM)
Display description
on the panel
- Number display [ 7 segments LED: 5digits (VS-5F, VS-5F-1 is 3 digits) ]
Parameter No., switch No., dog No., program No.
- Data display [ 7 segments LED: 3 digits + 0.5°(Decimal point display) ]
Setting value, current position value, rotation speed, ON/ OFF state of the switch output
- Operation state indicator
System ready, program selecting method, system error, mode selection,
ON/OFF selection when setting the switch, communication state
- Error code when occurring an error
Input description
from panel side
- Program No., switch No., dog No.
- Parameter, switch data
- Error cancel
- TEACH input
- Mode selection
Auxiliary functions
- External origin set function (VS-5FX, VS-5FX-1)
-Timing pulse function
- Motion detection switch output function
- Hysteresis function
- Protected switch function
- Switch output enabling function
- External error cancel input
- Arbitrary pulse output
- Current position value output (BCD, gray code (720-division)) / Speed output (binary code)
(VS-5FD, VS-5FD-1, VS-5FX, VS-5FX-1)
- Password function (only for SP1)
Communication functions
- RS-232 communication
(The setting value can be saved, loaded monitored. Moreover, RUN operation is available.)
- Connectable with the Touch Panel (VARIMONI)
- Connectable with the external display unit (NDP)
- Connects with MELSEC (MC protocol) or MELSEC-A (Bidirectional protocol)
- Connects with OMRON protocol
Applicable standard
Applicable VS-5F-1, VS-5FD-1, VS-5FX-1
UL508
CSA C22.2 No.142 (Compliance with c-UL standard)
CE Marking (EMC directive)
KC mark (Korea Certification Mark)
