26
Cleaning / Checking the Irrigation Nozzle
9 – 1 – 2 Automated Cleaning
Automated Cleaning with Cleaning Tools
Use the Cleaning Tools according to the following system figure.
Drying
Cleaning Adaptor INCleaning Tube 1.5/L25
Cleaning
Air Gun
Irrigation Nozzle
Luer-lock syringe
_ Pre-cleaning
1
Remove contaminants on the surface with a cloth or soft bristle
brush under running tap water.
≤ 38°C, ≥ 3.5 L/min, ≥ 15 sec.
Water quality: Drinking water
2
Mount the Cleaning Adaptor IN and the Irrigation Nozzle to the
Cleaning Tube 1.5/L25.
Pull the Cleaning Adaptor IN to make sure that it is securely
connected.
* If the Cleaning Tube 1.5/L25 is deteriorated, replace it with a
new one.
3
Screw the disposable luer-lock syringe (hereafter referred to as
syringe) into the Cleaning Adaptor IN.
4
Suck tap water from the product tip and discharge it.
Perform this step 5 times.
≤ 38°C
Water quality: Drinking water
x5
5
Remove the Cleaning Tube 1.5/L25 and the Cleaning Adaptor IN
from the Irrigation Nozzle.
To Next Page
