NTI Trinity TX51 - Near Boiler Vent Connections (SS - Stainless Steel)

Tx I&O Manual │General Venting
15
Figure 4-2(c) Near Boiler Vent Connections (SS – Stainless Steel)
Exhaust Vent Preparation (SS)
Near Boiler Venting (SS)
Flue Outlet
Adapter (factory
supplied)
SS Exhaust
Vent Pipe
Swing Joint
to attain slope in
horizontal runs
SS Air-inlet Pipe
SS Adapter
(Table 4-3)
Air-inlet Adapter
(factory supplied)
SS Adapter (Table 4-3)
PPs Gasket & Ring –
remove lower gasket &
ring (not used w/ PVC)
PVC Gasket & Ring – retain
upper gasket & ring
