Ntron MICROX - Menu 2 - Analogue Output FSD; Menu 3 - Set 4 Ma Output

Microx User Manual
Rev. 1.2
V233P
Page 19
4.2.2 Menu 2 – Analogue output FSD
• Press the MENU button to open the menu system.
• Using the NEXT and PREVIOUS buttons select menu option:
E:2
• Press ENTER.
• Using the INCREASE and DECREASE buttons adjust the FSD
to the required level.
• Press ENTER.
Note: Pressing the MENU button rather than the ENTER
button exits the sensor FSD feature without any change.
• Press the MENU button to close the menu system.
Note: The Sensor FSD will be displayed on exit while the
MENU key is pressed.
4.2.3 Menu 3 – Set 4 mA output
• Monitor the current sourced from the analogue output of the
OEM module using a multimeter set to read milliamps.
• Press the MENU button to open the menu system.
• Using the NEXT and PREVIOUS buttons select menu option:
E:3
• Press ENTER.
• Using the INCREASE and DECREASE buttons adjust the
output to 4mA .
• Press ENTER.
Note: Pressing the MENU button rather than the ENTER
button exits the 4 mA feature without performing the
calibration.
• Press the MENU button to close the menu system.
Note: The 4 mA factor will be displayed on exit.
