4.2.4 Menu 4 – Set 20 mA output
• Monitor the current sourced from the analogue output of the
OEM module using a multimeter set to read milliamps.
• Press the MENU button to open the menu system.
• Using the NEXT and PREVIOUS buttons select menu option:
E:4
• Press ENTER.
• Using the INCREASE and DECREASE buttons adjust the
output to 20 mA.
• Press ENTER.
• Press the MENU button to close the menu system.
Note: The 20 mA factor will be displayed on exit.
4.2.5 Menu 5 – Analogue Output Simulation
The Microx analogue output can be tested for functionality via menu 5.
This option allows the user to simulate the analogue output.
• Press the MENU button to open the menu system.
• Using the NEXT and PREVIOUS buttons select menu option:
E:5.
• Use the UP and DOWN button to increase or decrease the
analogue output. The value displayed on the Microx display will
be equivalent to the analogue output.
• Press the MENU button to close the menu system.
Note: The module will return to the conditions on entry.
