Ntron MICROX - 2 SPECIFICATION

Microx User Manual
Rev. 1.2
V233P
Page 7
2 SPECIFICATION
Supply
Input Voltage
Options:
24V DC nominal.(Good quality power supply)
110-240VAC Panel and Wall mount versions only.
Supply current:
140 mA at 24VDC nominal , all relays energised,
20 mA drawn on current loop.
Outputs
Analogue Output:
4-20mA analogue output (10-bit resolution)
Current Source.
Relays (Optional)
3
Single pole change over.
Rating 6 Amps 250 v AC
Fuses
Fuse
500mA anti-surge on board fuse for circuit
protection.
Additional Features
Display:
4 Digit, 7 Segment Display.
Keypad:
4-Button Keypad
Dimensions:
See the appropriate diagram on page 7 this
manual.
IP Rating
IP20. Wall mount version is IP65.
Terminals
capacities:
0.2-4.0mm Solid wire
0.2-2.5mm Stranded wire
Software:
Software configuration, calibration and data
logging provided by PC communications.
RS232 Output
Communications with PC @ 19200 baud.
