Changing the floor tool blades
Lower the oor tool then unscrew the retaining knobs and slide it o the holding bracket.
Rinse the oor tool assembly with clean water and ret.
Periodically the oor tool blades should be examined and checked for wear and damage.
Replacement is a reversal of the removal process.
Floor Tool Overview
1. Front blade (slotted)
2. Blade carrier
3. Rear blade
4. Floor tool main body
5. Retaining pins x 4
!!
Remove oor tool. Remove four retaining pins.
Turn the oor tool over. Separate the blade carrier from the main body. Peel away blades.
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR TO ANY MAINTENANCE.
!!
NOTE: THE BLADES ARE DESIGNED TO BE REVERSIBLE,
THUS EXTENDING THEIR USEFUL WORKING LIFE.
