Machine set-up guide
6
www.numatic.co.uk
The U-bend in the hose prevents water spillage when the vacuum is switched o.
Ret vacuum hose to the oor tool when nished.
Hose U-bend clip
Fitting Dump Hose
NOTE: DO NOT push the vacuum hose onto the oor tool with the oor tool in the raised position.
Slide oor tool onto bracket. Tighten retaining knobs to nger tight
and attach hose.
Raise the oor tool.
The oor tool design incorporates a safety knock-o feature, this allows it to safely
disengage from its mounting should it become caught on an obstruction during
forward movement.
Please ensure you do not over tighten the retaining knobs.
Break-away floor tool
Fitting the floor tool
NOTE: Raise oor tool before driving to the cleaning area.
The machine will not operate in reverse with the oor tool lowered.
Lower the oor tool.
Lower the oor tool arm by moving the release lever to the upper position (Fig.1).
NOTE: MACHINE WILL NOT REVERSE WITH FLOOR TOOL IN THE LOWERED POSITION.
!!
