12
Machine Operation
Pre-scrub mode
The TTB Range has been designed to cope with a variety of oor types and different levels of soiling.
On heavily soiled oors use a ‘double scrub’ technique.
First pre-scrub the oor with the oor-tool in the raised position, allow the chemical time to work, then scrub the area a
second time with the oor-tool lowered.
Floor tool in use
The clean-water / chemical mix is dispersed via the ‘THRU-FEED’ system.
The waste water is then retrieved by the oor-tool.
Overlap the scrubbing path by 10cm to ensure an even clean (Fig.23).
Fig.23
Fig.24
Refer to (Fig.20) to raise and lower the oor-tool.
If streaking occurs, wipe
the oor-tool blades
clean (Fig.24).
Breakaway oor-tool
The oor-tool design incorporates a safety knock-off feature.
Allowing it to safely disengage from its mounting should it
become caught on an obstruction, during forward machine
movement (See Fig.26).
To re-attach the oor-tool blade to its holder.
First loosen the retaining knobs on the oor-tool body and slide
onto the holding bracket.
Tighten retaining knobs to nger tight.
Note: Care must be taken to reduce speed when cornering or when manoeuvring around obstacles.
Note: The machine will still reverse with the oor-tool in the lowered position, this could possibly damage the blades.
Raise the oor-tool before reversing.
Fig.26
Fig.25
