Numatic TTB 4045/100 Owner's Instructions

18
PROBLEM CAUSE SOLUTION
Machine will not operate
Missing or blown fuses
Battery not connected
Low battery charge
Fit or replace fuse (page 8)
Connect battery (page 8)
Charge batteries (page 16)
Vacuum will not operate Vacuum not turned on Turn on vacuum (page 13)
Poor water pick up
Waste-water tank full
Clogged / blocked vacuum hose
Loose hose connections
Debris basket lter clogged / blocked
Separator lter clogged / blocked
Poor separator seal
Damaged separator seal
Damaged / split vacuum hose
Damaged oor-tool blades
Low battery charge
Empty waste-water tank (page 14)
Remove and clean (page 14)
Push tight connections (page 14)
Remove and clean (page 14)
Remove and clean (page 14)
Clean and ret (page 14)
Renew (contact service department)
Renew (contact service department)
Renew (contact service department)
Recharge batteries (page 16)
No brush / scrub function
No brushes tted
Brush overloaded
Check and t (page 10)
Reset machine (page 13)
Little or no water ow
Clean-water tank empty
Clean-water tank lter blocked / clogged
Clean water tap not turned on
Fill clean-water tank (page 11)
Remove and clean (page 14)
Turn on clean water tap (page 9)
Machine just ‘stops’ while
operating
Too much load on the brush system
Blown fuse in Battery pack
Reset the machine and decrease the brush load to best
suit the oor type (page 13)
Replace 50 Amp fuse (page 8)
Trouble Shooting
TTB 4045/100, TTB 4055/100 & TTB4552/100
TTB 4045/100
Capacity Brush Motor Vac Motor Brush Sizes
Pad
Sizes
Weight Protection Class Power
40 L 400W 400W 450mm 400mm 128Kg IPX4 2 x 12V (24V) 100Ah
Fluid Flow Speed Run Time
Recharge
Time
Cleaning
Speed
Hand Arm
Vibration
Noise Size
0-2L/Min 100 rpm 2.5hrs 8 hrs 0-4kph 0.54m/s
2
≤ 70 dB(A)
Width - 470mm
Length - 1075mm
Height - 1160mm
TTB 4552/100
Capacity Brush Motor Vac Motor Brush Sizes
Pad
Sizes
Weight Protection Class Power
40 L 2 x 400W 400W 2 x 280mm 2 x 280mm 134Kg IPX4 2 x 12V (24V) 100Ah
Fluid Flow Speed Run Time
Recharge
Time
Cleaning
Speed
Hand Arm
Vibration
Noise Size
0-2L/Min 120 rpm 2hrs 8hrs 0-4kph 0.57m/s
2
≤ 70 dB(A)
Width - 565mm
Length - 1145mm
Height - 1160mm
TTB 4055/100
Capacity Brush Motor Vac Motor Brush Sizes
Pad
Sizes
Weight Protection Class Power
40 L 400W 400W 550mm 500mm 130Kg IPX4 2 x 12V (24V) 100Ah
Fluid Flow Speed Run Time
Recharge
Time
Cleaning
Speed
Hand Arm
Vibration
Noise Size
0-2L/Min 100 rpm 2.5hrs 8hrs 0-4kph 0.57 m/s
2
≤ 70 dB(A)
Width - 560mm
Length - 1115mm
Height - 1160mm

Numatic TTB 4045/100 Specifications

General

Brand	Numatic
Model	TTB 4045/100
Category	Scrubber
Language	English
