Numatic TTB 4045/100 Owner's Instructions

3
Machine Overview
3
4
5
6
8
10
9
1
7
12
14
15
16
17
11
2
13
18
19
20
17
1 Fuse 11 Clean-water ller cap
2 Waste-water tank 12 Floor-tool vacuum hose
3 Clean-water tank 13 Vacuum hose
4 Brush deck 14 Isolator Key
5 Clean Water Filter 15 Floor-tool Lifting Lever
6 Rear wheels 16 Hour Meter - TTB machines only
7 Clean water On / Off tap 17 Floor-tool retaining knobs
8 Separator 18 Squeegee blades
9 Clean-water emptying hose 19 Deck Locking Mechanism
10 Top tank (waste water) drainage hose 20 Clean-water ller hose
21 Operator control panel
21
21

Numatic TTB 4045/100 Specifications

General

Brand	Numatic
Model	TTB 4045/100
Category	Scrubber
Language	English
