Numatic TTB 4045/100 Owner's Instructions

9
Fitting the Brush / Pad.
Push in the deck locking pin
(Fig.10) and rotate the
brush deck into the
operating position (Fig.11).
Turn on the clean water tap (Fig.12).
To start: hold either on / off trigger and press the yellow on / off switch once
(Fig.13).
Brush, vacuum and water settings can be controlled by the control panel
(See Page 13).
Fill the clean-water tank to a Max of 40 litres (see page 11)
For operation and cleaning controls (see page 13)
In the event of a breakdown contact your Numatic dealer or the
Numatic Technical helpline +44 (0)1460 269268
Fig.12
Fig.11
Fig.13
On
Off
Off-Aisle Cleaning Kit (Optional Extra Accessory)
TTB = 38mm Ø 606182
Fig.10
