Regular Maintenance
Remove the two hoses to disconnect the separator from the
machine (1 & 2).
Remove xing band holding separator in place (3).
Lift o󰀨 the separator. The separator has a sealing-rubber which
should be examined at every clean-down (4).
Rinse using clean water.
ALWAYS ENSURE THAT THE BATTERY IS REMOVED
PRIOR TO ANY MAINTENANCE OPERATION
!!
After use, empty waste-water tank using
emptying hose and ush-out with clean
water. (g.A).
The clean-water tank can be drained via
the red cap tted to the left hand side
of the machine. There is a sealing bung
beneath the red cap (ensure the sealing
bung is clean) The cap should only be
done up by hand. (g.B).
Emptying Top Tank
Separator
Emptying Bottom Tank
A
1
2
3
6
5
4
B
Remove the lter and basket clipped into the separator and ush with clean water (5 & 6).
Replace the lter by rst tting the rear of the lter rst then clipping in the front to lock in place (5).
