Numatic TTB1840NX - Machine Set-up Guide; Fitting the Brush Pad and Floor-tool

6
www.numatic.co.uk
Swing the oor-tool carrier to the
side of the machine. (Fig.1).
Secure to the carrier using the two
knobs tted to the oor-tool carrier
(Fig.2) - (Fig.3).
Do not over tighten the retaining
knobs.
Ensure inspection cap is in place on
the uid pipe. (Fig.4) - (Fig.5)
For tting the oor-tool blades
(See Page 10).
Machine Set-up Guide
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
!!
400mm Brush / 360mm Pad.
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making tting and removal a simple process.
Slide the brush / pad under the brush deck.
Fit the brush / pad onto the Nulock drive chuck, twist to lock the brush / pad in place.
Safety gloves are recommended for the changing of used brushes.
Turn on the clean water tap.
Fitting the Brush / Pad / Turn on water
Fitting the Floor-tool
The oor-tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-o󰀨 feature if the
oor-tool gets snagged, whilst in transit.
NOTE:Itiseasiertottheoor-tooliftheweightofthemachineisrestingonthebrush.Ensurethebrushisttedrst.
1
2
3
4
5
