Numatic TTB1840NX - Filling the Clean Water Tank and Fill Level Indicator; Water Flow Adjustment

7
T 01460 68600
Machine Set-up Guide
NOTE: Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc.) are not allowed to enter the clean
watertankduringthellingprocess.Ifusingasuitablecontainer,ensureitisalwayscleanandfreefromdebris.
The TTB 1840 is equipped with a large 18 litre clean-water tank allowing large areas to be cleaned in a single ll.
Filling the Clean Water Tank
Fill Level Indicator
Water Flow Adjustment
To ll the clean-water tank, remove the ller cap (Fig.1). Fill using a hose or a suitable container (Fig.2).
Use the ll indicator (Fig.3).
1
2
3
Fill Indicator
A
1
2
B
Showing the clean-water tank full
(Fig.B)
Showing the clean-water tank empty
(Fig.A)
Located on the left of the machine is the On / O󰀨 water tap (Fig.1).
Set the tap to enable the cleaning solution .(Fig.2).
