T 01460 68600
Quick Set-up Guide
TTB 1840 36V CONTENTS
●
Owner Manual
●
Battery & Charger Manual
●
Battery Charger & Lead
●Battery●
Scrub Brush
●
Squeegee Assembly
Using the handle position lever, (Fig.1)
Move the handle into the upright position,
(Fig.2)
Slide the brush / pad under the brush
deck (Fig.3).
Fit the brush / pad onto the Nulock drive
chuck, twist to lock the brush / pad in
place (Fig.4).
Swing the oor-tool carrier from behind
the brush. Using the two locking knobs
tted to the oor-tool, secure the
oor-tool to the oor-tool carrier (Fig.5).
Fill the clear-water tank to Max of 18 litresSlide the battery into the
battery compartment (Fig.6)
Close the exible lid making sure it is
sealed correctly. (Fig.7)
PLEASE READ BEFORE COMMENCING ANY OPERATION. AFTER THE REMOVAL OF ALL
THE PACKAGING, CAREFULLY OPEN AND CHECK THE CONTENTS.
!!
ALWAYS ENSURE THAT THE FLOOR IS PRE-SWEPT
AND RELEVANT SAFETY SIGNS ARE DISPLAYED.
! !
