Nuna mixx2 User Manual

2120
EN EN
Adjusting the Recline
1 - There are 5 positions for the backrest.
To recline the backrest, squeeze the adjustment
handle, and pull seat down to desired position.
To raise the backrest, squeeze handle and rotate seat
to upright position.
Adjusting the Calf Support
The calf support has 3 positions.
2 - To raise the calf support, lift it up as shown.
3 - To lower the calf support, press in both buttons on the
sides and rotate the calf support downward.
Full Reclined Position
WARNING
• Child may slip into leg openings and strangle.
• NEVER use in full reclined position unless the calf
support is raised to cover the front opening.
• DO NOT use enclosure with an older child that can push
up on hands and knees or crawl out.
When using the stroller in fully reclined position, follow
these steps:
4 - Remove the arm bar.
5 - Fully recline seat, rotate footrest to upright position
and unfasten the aps underneath the calf support.
6 - Fasten the aps to the snaps on the inside of the
seating area on both sides of the seat.
2
1
3
4
6
5

Nuna mixx2 Specifications

General

Weight Capacity	50 lbs
Recline Positions	5
Harness Type	5-point
Wheel Type	All-terrain
Seat Recline Positions	5
Seat Facing Directions	Forward and Parent-facing
Suspension	All-wheel suspension
Frame Material	Aluminum
Brake Type	One-touch, rear wheel
Stroller Height	44.3 inches
Stroller Width	23.5 inches
Folded Width	23.5 inches
Seat Width	12 inches (30.5 cm)
Seat Depth	9 inches (23 cm)
Canopy	Extendable UPF 50+ canopy with flip out eyeshade
Front Wheel Size	7.5 inches
Brakes	One-touch, rear wheel
Compatible Car Seats	Nuna PIPA series
Fabric Material	Polyester
