Nureva SPAN - Install NAM Image Alignment Module; Attach NAM to Brackets

14
February 2017
If you are using the mounting
brackets, attach them to
the NAM using the screws
provided on the sides of the
NAM.
3.3.1
Install the NAM image alignment module3.3
R
S
If you are mounting the
NAM(s), use the #6 screws
and appropriate anchors a
minimum of 5” (12.7 cm) away
from the projector mounting
plate.
3.3.2
