TECHNICAL INFORMATION
The SPL Series are hydraulic asymmetric two post lifts with a lifting capacity of 8,000, 9,000 and 10,000 pounds. These
lifts feature a powerful 3.5hp integrated power unit and covered hard-chromed cylinders, making them a precisely
engineered mix between durability and appearance. With a wide range of features and options to choose from, the SPL
is the perfect lift for your shop.
ACCESSORIES / OPTIONS
• Wide range of pick up pads / adapters
• XL models (SPL 10000 MXL3S) extend lifting height over 80”
• Electrical options 208/230V / 3 phase, 460/480V / 3 phase and 575/600V / 3 phase
• Optional triple-extended arms with screw up adaptors - 3S
• Optional low-profile arms with 3” clearance and screw up adapters – LP
• Optional Double-Jointed arms with 5.2” clearance and screw up adapters – DJ
Technical Data
Standard arms
Three stage arms
Low profile arms
Double-jointed arms
Lifting Capacity(lbs.)
10,000
10,000
8000
9000
Lifting Time
Approx.(sec)
37
37
37
37
Low Clearance(in)
4.5”
5”
3”
5.2”
Rear arms
extension(in)
39.5-59”
39.5-59”
33-54.3”
0-71.86”
Front arms
extension(in)
27.25-43.5”
21.5-43.5”
23.2-34”
21.5-43.5”
Lifting Height(in)
73.5”
73.5”
73.5”
73.5”
Overall Height(in)
142.75”
142.75”
142.75”
142.75”
Inside Height(in)
139.2”
139.2”
139.2”
139.2”
Lifting Height(in)-XL
80.5”
80.5”
80.5”
80.5”
Overall Height(in)-XL
160”
160”
160”
160”
Inside Height(in)-XL
155.5”
155.5”
155.5”
155.5”
Overall width(in)
124”
124”
124”
124”
Outside column
width(in)
120”
120”
120”
120”
Inside column
width(in)
105”
105”
105”
105”
Drive through inside
width(in)
94.75”
94.75”
94.75”
94.75”
Motor(hp)
3.5
3.5
3.5
3.5
Power Supply(V)
208/230/1 Ph(std)
208/230/1 Ph(std)
208/230/1 Ph(std)
208/230/1 Ph(std)
Load Distribution
3333 Rear arms; 1667 Front arms
Lifting Time
approximately 45 seconds
Lowering Time
Variable, operator controlled
Power Rating
2HP, 23 amp Max
Motor Speed
3450 rpm
Pressure Relief Valve
3480 PSI
Oil Tank Capacity
4 gallons
