SHIPPING/PARTS LIST
QUANTITY
ITEM CODES
ITEM NAMES
LOCATION?
1
Manual/Handbook
Box
2
245SPL05168
Threaded Rod – To be installed on Guide Cables if the Extension is
needed for a wider width.
Box
2
232POW05169
Hex Nut –
4
9DM1620HNZN
NutM16-2.0 Fin Hex Zinc Din934 – Pre-installed on Tension Rods.
2
2100SPL08276
Holder for Extension –Black plate with three holes.
Box
4 245SPL08031
Extension 3.5" – Silver Rods used to fill space between the Lift Carry
Arms and vehicle. Will be used with the Lift Adapter Pads. Box
4
245SPL08032
Extension 1.5" – Silver Rods used to fill space between the Lift Carry
Arms and vehicle. Will be used with the Lift Adapter Pads.
Box
4
2100SPL28217
Lift Adapter Pad – Round rubber pads to be placed in peg holes on
the Lift Carry Arms to support the vehicle.
Box
1
2100SPL05127
Lock Release Lever – To be installed above Motor on the Locking
Mechanism. Used to open Locks to lower the vehicle.
Box
1
9RCable3327X19GAC
Manual Latch Release Cable – Silver cable to be mounted on Locking
Mechanism from Post 2 to Post 1.
Box
1
9720290
Ball Knob – Black threaded ball to be installed on end of Lowering
Lever as part of the handle.
Plastic Bag
1 94515-06-06
90 Degree 3/8 Fitting
– Used to connect Hydraulic Line to Motor. Plastic Bag
4
9SRD471
Metric Snap Ring 38MM – Silver C-Clips.
Plastic Bag
4 9HHCSM08X125020Z
Hex Head Cap Screws M8x20
– Used to mount Lift Motor to th Post. Plastic Bag
8
WM0800000ZNF000125
Flat washer M8 – Used to mount Lift Motor to Post.
Plastic Bag
4 9NUTM08125ZNH0NY0985
Locknut M8 Nylon Insert
– Used to mount Lift Motor to Post. Plastic Bag
4
9HHCSM10X150020Z
Hex Head Cap Screws M10x20 – For Overhead Telescope Assembly.
Plastic Bag
4
9SHCSM06X10010Z
Socket Head Cap Screw M6 x10 – For Extension Holder.
Plastic Bag
4
9WM10000000ZNF000125
Flat washer M10 – For Overhead Telescope Assembly.
Plastic Bag
1 2100SPL05101
Post Assembly #1
with Hydraulic System and Cables pre-installed. Pallet
1
2100SPL05131
Post Assembly #2 with Hydraulic System and Cables pre-installed.
Pallet
2 2100SPL08801
Long Lift Carry Arms
– To support the back of vehicle. Pallet
2
2100SPL08820
Short Lift Carry Arms – To support the front of vehicle.
Pallet
4 245SPL28016
Pivot Pins
– To attach the
Lift Carry Arms
to the Yokes. Box
1 2100SPL05080
Overhead Telescope – Ships pre-assembled for short width
assembly. Pallet
1 AB-10679
Hydraulic Power Unit (Boxed) – To be mounted on Post 1 Motor
Mounts. Pallet
UNPACKING LIFT
Carefully remove the Lift from the shipping crate.
Verify that all parts match the parts list.
