14
Cover: Removal and Installation
1.
2.
3.
Remove seat rail
bumpers.
Remove seat rail cap.
The T4 seat assembly is
heavy; it weighs 50 lbs
(23 kg). To avoid injury, or
damage to the product, use
caution when removing or
installing. Obtain assistance
as required. Use proper lifting
technique.
Roll seat off of seat rail.
Keep upward pressure on
front of seat to prevent
scratching end of seat rail.
k" Y/;JJ;8:":97>GI7;F>7
k" $a(X"G7>19/
k" @970=9/"0GJ"R5:>"=4"0J;<1"
/4J>:"C>647>":97>G:S
Tools Required:
4.
Remove 6 screws from
top cover.
Note: In center of top cover,
only 2 screws are used in the
forward 2 holes.
CAUTION
!
To Next Page
