NUTOOL MC550 - ELECTRICAL INFORMATION; CONNECTION OF THE MAINS PLUG

18
GB
ELECTRICAL INFORMATION
CONNECTION OF THE MAINS PLUG
Important!Thewiresinthemainsleadfittedtothisproductarecolouredinaccordancewiththefollowingcode:
THISPRODUCTREQUIRESACONNECTIONTOEARTH.
THE3PINPLUGMUSTCOMPLYTOBS1363/A.
FUSEMUSTCOMPLYTOBS1362.
Brown:Live(L)orRed
Blue:Neutral(N)orBlack
Green&Yellow or Green:Earth(E)
If for any reason the 13 amp plug fitted to this product requires replacement it must be wired in accordance with the following
instruction:
DO NOT CONNECT THE BROWN LIVE OR BLUE NEUTRAL TO THE EARTH PIN MARKED ‘E’ ON THE 3
PIN PLUG.
ConnecttheBluewiretotheterminalmarkedNeutral(N).ConnecttheBrownwiretotheterminalmarkedLive(L).ConnecttheGreen
andYellow(orGreen)wiretotheterminalmarkedEarthE .Ensurethattheouterinsulationisgrippedbythecordgripandthat
thewiresarenottrappedwhenreplacingtheplugcover.Themainsleadonthisproductisfittedwitha13amp(BS1363/A)plug.A
5 amp(BS1362)fusemustbefittedintheplug.
IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN
Therearenouserserviceablepartsinsidethisproductexceptthosereferredtointhemanual.Alwaysreferservicingtoqualified
servicepersonnel.Neverremoveanypartofthecasingunlessqualifiedtodoso;thisunitcontainsdangerousvoltages.
WARNING!
Foryourprotectionifthisproductistobeusedoutdoorsitshouldnotbeexposedtorainorusedindamplocations.Donotplace
theproductondampsurfaces,useaworkbenchifavailable.Foraddedprotectionuseasuitableresidualcurrentdevice(R.C.D.)at
thesocketoutlet.
If an extension cable is to be used with this product it must be of 3 core construction with the earth conductor connected at both the
plugandsocket.Ifindoubtconsultaqualifiedelectrician.
