12
The encoder button has two physical movements. The button turn clockwise and anticlockwise
to increase or decrease the temperature and time values of the program. Also, the button press
for select / confirm.
04-Start / Stop Button
Used button to start the device to operating at set values or to stop the operation.
05-Heating Lamp
The led is “on” during heating, it indicates that the heating process is carried out.
06-“Operating The Program” Lamp
A lamp indicating that the program is running as soon as the device is started.
07-Data Transfer Lamp
The lamp indicates that the records are transferred in the memory or the file is transferred
during software update.
08-Alarm Led
This led flashes when there is a warning or error on the device.
09-“End of The Program” Lamp
It is a warning lamp that indicates that the running program is finished.
10-Usb Lamp
This lamp is on when connected to a USB external memory.
11-Back / Alarm Mute Button
This button is used to silence audible alarms in case of error and cancel the changes in the
menu.
5.8. PRIOR TO OPERATION
• Plug-in the instrument to correctly grounded sockets.
• Push the power switch. See that the power lamp is turn on.
• See that the microprocessor control system is activated.
• Learn the function of the control panel (See 5.7).
• Set the temperature value according to your need (See Section 6.2).
