13
1- Chamber Manometer: Shows the pressure in the chamber.
2- Generator Manometer: Shows the pressure in the generator that produces the steam.
3- Jacket Manometer: Shows the pressure within the jacket surrounding the chamber.
4- Gasket Manometer: Shows the pressure in the gasket channel.
5- Touchscreen: Screens having imaginary buttons on top are called touchscreens. These
buttons are activated by patting the requested commands shown on the screen. It is the
interface utilized by the user to communicate with the control unit that bears the information
for operation.
6- Panel Type Printer: A thermal printer that is used to print the completed program or any
program recorded in the memory. The output involves parameters such as the sterilization
phases, pressure-temperature data during sterilization phases time and installation settings.
