NUVE NC 300 - Technical Specifications; Technical Specifications Table; Precautions and Limitations on Use

6
2. TECHNICAL SPECIFICATIONS
2.1. TECHNICAL SPECIFICATIONS TABLE
Technical
Specifications
NC 300
NC 430
NC 570
NC 710
Power Supply
400VAC, 3 phases + neutral + ground
Power Supply
Frequency
50/60 Hz.
Power Consumption
29 kW
38 kW
50 kW
62 kW
Control System
Microprocessor
Air Pressure
4 – 6 bar
Chamber Material
Grade 316L stainless steel
Generator Material
Grade 316L stainless steel
Jacket Material
Grade 316L stainless steel
No. of Sterilization
Programs
7 standard, 1 liquid, 1 drying, 50 special
Sterilization
Temperatures (⁰C)
121 – 125 – 134 – 136
Maximum Pressure
3,0 bars
Maximum
Temperature
144 ⁰C
Temperature Sensors
PT-100
Test Programs
Vacuum, Bowie&Dick
Max chamber pressure
3,0 bars
Max Jacket Pressure
3,0 bars
Max Generator
Pressure
3,0 bars
Volume (Liter)
300
430
570
710
STU capacity
(1 STU 300x600x300
mm)
4
6
8
10
Chamber Dimensions
(W x D x H), mm
635 x 722 x 655
635 x 1034 x 655
635 x 1371 x 655
635 x 1708 x 655
External Dimensions
(W x D x H), mm
1140 x 1290 x
1910
1140 x 1330 x
1910
1140 x 1660 x
1910
1140 x 2000 x
1910
Weight (Kg)
860
980
1120
1260
3. PRECAUTIONS AND LIMITATIONS ON USE
The user shall pay attention to the following:
 Do not operate the instrument for purposes other than its main purpose.
 The set-up, installation, initial functioning, service, maintenance and transportation shall be
handled by authorized personnel appointed by the manufacturer.
